ST2305 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ST2305
|
|
حجم فایل
|
52.776
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
STANSON Tech. ST2305
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
1.25W
-
Total Gate Charge (Qg@Vgs):
10nC@4.5V
-
Drain Source Voltage (Vdss):
20V
-
Input Capacitance (Ciss@Vds):
485pF@10V
-
Continuous Drain Current (Id):
3.5A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.5V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
40pF@10V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
63mΩ@4.5V,3.5A
-
Package:
SOT-23
-
Manufacturer:
STANSON Tech.
