دیتاشیت NCE0224D
مشخصات دیتاشیت
| نام دیتاشیت |
NCE0224D
|
| حجم فایل |
78.721
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Wuxi NCE Power Semiconductor NCE0224D
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
150W
-
Total Gate Charge (Qg@Vgs):
60nC@10V
-
Drain Source Voltage (Vdss):
200V
-
Input Capacitance (Ciss@Vds):
4.2nF@25V
-
Continuous Drain Current (Id):
24A
-
Gate Threshold Voltage (Vgs(th)@Id):
3V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
75pF@25V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
64mΩ@10V,15A
-
Package:
TO-263
-
Manufacturer:
Wuxi NCE Power Semiconductor
