SMAJ78A Datasheet
Datasheet specifications
|
Datasheet's name
|
SMAJ78A
|
|
File size
|
94.724
KB
|
|
File type
|
pdf
|
|
Number of pages
|
6
|
Technical specifications
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/TVS
-
Datasheet:
GOODWORK SMAJ78A
-
Breakdown Voltage:
86.7V
-
Maximum Clamping Voltage:
126V
-
Reverse Leakage Current (Ir):
5uA
-
Reverse Stand-Off Voltage (Vrwm):
78V
-
Peak Pulse Current (Ipp)@10/1000us:
3.2A
-
Package:
SMA(DO-214AC)
-
Manufacturer:
GOODWORK
-
Peak Pulse Current (Ipp)@10/1000μs:
3.17A
-
Unidirectional Channels:
1
-
Peak Pulse Power Dissipation (Ppp)@10/1000us:
400W
