2016L075/60MR Datasheet
Datasheet specifications
| Datasheet's name | 2016L075/60MR |
|---|---|
| File size | 94.367 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet 2016L075/60MR |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: Littelfuse 2016L075/60MR
- Hold Current: 750mA
- Trip Current: 1.5A
- Power Dissipation: -
- Current Rating (Max): 20A
- Maximum Time to Trip: 500ms
- Operating Temperature: -40°C~+85°C
- Operating Voltage (Max): 60V
- Resistance - Initial (Ri) (Min): 130mΩ
- Resistance - Post Trip (R1) (Max): 900mΩ
- Package: 2016
- Manufacturer: Littelfuse
