RS2G-B 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: AnBon RS2G-B
- Diode Configuration: Single
- Reverse Voltage (Vr): 400V
- Operating Temperature: -55°C~+150°C@(Tj)
- Forward Voltage (Vf@If): 1.3V@2A
- Reverse Leakage Current: 5uA@400V
- Reverse Recovery Time (trr): 150ns
- Average Rectified Current (Io): 2A
- Package: SMB(DO-214AA)
- Manufacturer: AnBon
