دیتاشیت AZ1117CH-3.3TRG1
مشخصات دیتاشیت
| نام دیتاشیت |
AZ1117CH-3.3TRG1
|
| حجم فایل |
78.189
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
23
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Diodes Incorporated AZ1117CH-1.8TRG1
-
Output Type:
Fixed
-
Output Current:
800mA
-
Output Voltage:
1.8V
-
Dropout Voltage:
1.3V@(800mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
15V
-
Operating Temperature:
-20°C~+125°C@(Tj)
-
Quiescent Current (Ground Current):
6mA
-
Power Supply Rejection Ratio (PSRR):
70dB@(120Hz)
-
Package:
SOT-223
-
Manufacturer:
Diodes Incorporated
