DNBT8105-7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DNBT8105-7
|
|
حجم فایل
|
67.595
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
Diodes Incorporated DNBT8105-7
-
Transistor Type:
NPN
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Collector Current (Ic):
1A
-
Power Dissipation (Pd):
600mW
-
Transition Frequency (fT):
150MHz
-
DC Current Gain (hFE@Ic,Vce):
100@500mA,5V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
60V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
500mV@1A,100mA
-
Package:
SOT-23
-
Manufacturer:
Diodes Incorporated
