NTMFS4C13NT3G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTMFS4C13NT3G
|
|
حجم فایل
|
99.153
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi NTMFS4C13NT3G
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
21.6W
-
Total Gate Charge (Qg@Vgs):
7.8nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
770pF@15V
-
Continuous Drain Current (Id):
38A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.1V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
127pF@15V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
7.3mΩ@10V,30A
-
Package:
SO-8-FL-5.8mm
-
Manufacturer:
onsemi
