NTP7D3N15MC دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTP7D3N15MC
|
|
حجم فایل
|
88.805
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
7
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi NTP7D3N15MC
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
2.4W;166W
-
Total Gate Charge (Qg@Vgs):
53nC@10V
-
Drain Source Voltage (Vdss):
150V
-
Input Capacitance (Ciss@Vds):
4250pF@75V
-
Continuous Drain Current (Id):
12.1A;101A
-
Gate Threshold Voltage (Vgs(th)@Id):
4.5V@342uA
-
Reverse Transfer Capacitance (Crss@Vds):
15pF@75V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
6.2mΩ@10V,62A
-
Package:
TO-220
-
Manufacturer:
onsemi
