NTZD3155CT2G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NTZD3155CT2G
|
|
حجم فایل
|
98.818
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Type:
1PCSN-Channel&1PCSP-Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
onsemi NTZD3155CT2G
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
250mW
-
Total Gate Charge (Qg@Vgs):
2.5nC@4.5V
-
Drain Source Voltage (Vdss):
20V
-
Input Capacitance (Ciss@Vds):
150pF@16V
-
Continuous Drain Current (Id):
540mA;430mA
-
Gate Threshold Voltage (Vgs(th)@Id):
1V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
550mΩ@540mA,4.5V
-
Package:
SOT-563
-
Manufacturer:
onsemi
