74HC04D,652 Datasheet

74HCT04PW,112

Datasheet specifications

Datasheet's name 74HCT04PW,112
File size 63.482 KB
File type pdf
Number of pages 14

Download Datasheet 74HCT04PW,112

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • RoHS: true
  • Category: Logic ICs/Inverters
  • Datasheet: Nexperia 74HC04D,652
  • Input Type: -
  • Sink Current: 5.2mA
  • Source Current: 5.2mA
  • Number of Circuits: 6
  • Supply Current (Max): 2uA
  • Low level range (VIL): 0.5V~1.8V
  • Max Propagation Delay: 14ns@6V,50pF
  • High level range (VIH): 1.5V~4.2V
  • Supply Voltage(Single): 2V~6V
  • Package: SOP-14
  • Manufacturer: Nexperia
