CJK3401AH دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CJK3401AH
|
|
حجم فایل
|
56.218
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Jiangsu Changjing Electronics Technology Co., Ltd. CJK3401AH
-
Operating Temperature:
+150°C@(Tj)
-
Power Dissipation (Pd):
1.4W
-
Total Gate Charge (Qg@Vgs):
-
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
1.05nF@15V
-
Continuous Drain Current (Id):
4.2A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.3V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
85pF@15V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
41mΩ@10V,4A
-
Package:
SOT-23-3L
-
Manufacturer:
Jiangsu Changjing Electronics Technology Co., Ltd.
