74LV00AT14-13 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
74LV00AT14-13
|
|
حجم فایل
|
71.95
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Series:
74LV
-
Category:
Logic ICs/Gates
-
Datasheet:
Diodes Incorporated 74LV00AT14-13
-
Sink Current:
12mA
-
Source Current:
12mA
-
Supply Voltage:
2V~5.5V
-
Logic Gate Type:
NAND Gates
-
Number of Channels:
4
-
Low Level Range (VIL):
0.5V
-
Operating Temperature:
-40°C~+125°C
-
High Level Range (VIH):
1.5V
-
Propagation Delay Time:
7.5ns@5V,50pF
-
Quiescent Current (Max):
20uA
-
Package:
TSSOP-14
-
Manufacturer:
Diodes Incorporated
