HSU20N15A دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
HSU20N15A
|
|
حجم فایل
|
78.007
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
HUASHUO HSU20N15A
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
72.6W
-
Total Gate Charge (Qg@Vgs):
23nC@10V
-
Drain Source Voltage (Vdss):
150V
-
Input Capacitance (Ciss@Vds):
1.19nF@75V
-
Continuous Drain Current (Id):
23A
-
Gate Threshold Voltage (Vgs(th)@Id):
4V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
4pF@75V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
47mΩ@10V,10A
-
Package:
TO-252
-
Manufacturer:
HUASHUO
