DMP1100UCB4-7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
DMP1100UCB4-7
|
|
حجم فایل
|
85.411
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Diodes Incorporated DMP1100UCB4-7
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
670mW
-
Total Gate Charge (Qg@Vgs):
14nC@4.5V
-
Drain Source Voltage (Vdss):
12V
-
Input Capacitance (Ciss@Vds):
820pF@6V
-
Continuous Drain Current (Id):
2.5A
-
Gate Threshold Voltage (Vgs(th)@Id):
800mV@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
83mΩ@4.5V,3A
-
Package:
X2-WLB0808-4
-
Manufacturer:
Diodes Incorporated
