JCS4N60FC دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
JCS4N60FC
|
|
حجم فایل
|
81.562
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
14
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Jilin Sino-Microelectronics JCS4N60FC
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
40.8W
-
Total Gate Charge (Qg@Vgs):
17.5nC@10V
-
Drain Source Voltage (Vdss):
600V
-
Input Capacitance (Ciss@Vds):
642.1pF@25V
-
Continuous Drain Current (Id):
4A
-
Gate Threshold Voltage (Vgs(th)@Id):
4V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
3.06pF@25V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
2Ω@10V,2A
-
Package:
TO-220MF
-
Manufacturer:
Jilin Sino-Microelectronics
