دیتاشیت CSD18540Q5B
مشخصات دیتاشیت
| نام دیتاشیت |
CSD18540Q5B
|
| حجم فایل |
96.987
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Texas Instruments CSD18540Q5B
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
3.1W;195W
-
Total Gate Charge (Qg@Vgs):
53nC@10V
-
Drain Source Voltage (Vdss):
60V
-
Input Capacitance (Ciss@Vds):
4230pF@30V
-
Continuous Drain Current (Id):
100A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.3V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
2.2mΩ@10V,28A
-
Package:
VSON-8-CLIP
-
Manufacturer:
Texas Instruments
