74AHC86BQ,115 Datasheet

74AHC86PW,118

Datasheet specifications

Datasheet's name 74AHC86PW,118
File size 62.429 KB
File type pdf
Number of pages 14

Download Datasheet 74AHC86PW,118

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • RoHS: true
  • Series: 74AHC
  • Category: Logic ICs/Gates
  • Datasheet: Nexperia 74AHC86BQ,115
  • Sink Current: 8mA
  • Source Current: 8mA
  • Supply Voltage: 2V~5.5V
  • Logic Gate Type: XORGate
  • Number of Channels: 4
  • Low Level Range (VIL): 0.5V~1.65V
  • Operating Temperature: -40°C~+125°C
  • High Level Range (VIH): 1.5V~3.85V
  • Propagation Delay Time: 8.8ns@5V,50pF
  • Quiescent Current (Max): 2uA
  • Package: DHVQFN-14-EP(2.5x3)
  • Manufacturer: Nexperia
