JCS2N60V دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
JCS2N60V
|
|
حجم فایل
|
73.732
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Jilin Sino-Microelectronics JCS2N60V
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
44W
-
Total Gate Charge (Qg@Vgs):
15.3nC@10V
-
Drain Source Voltage (Vdss):
600V
-
Input Capacitance (Ciss@Vds):
380pF@25V
-
Continuous Drain Current (Id):
1.9A
-
Gate Threshold Voltage (Vgs(th)@Id):
4V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
7.6pF@25V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
3.8Ω@10V,1A
-
Package:
IPAK
-
Manufacturer:
Jilin Sino-Microelectronics
