1.0-B-5PW Datasheet

1.0-B-10PW

Datasheet specifications

Datasheet's name 1.0-B-10PW
File size 45.196 KB
File type pdf
Number of pages 1

Download Datasheet 1.0-B-10PW

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • RoHS: true
  • Pitch: 1mm
  • Category: Connectors/FFC/FPC Connectors
  • Datasheet: HDGC 1.0-B-5PW
  • Contact Type: Double-sided contacts/up and down connection
  • Mounting Type: Right-Angle
  • Locking Feature: No lock
  • FFC, FCB Thickness: 0.3mm
  • Height Above Board: 4.4mm
  • Number of Contacts: 5P
  • Operating Temperature Range: -20°C~+85°C
  • Package: Push-Pull,P=1mm(交错脚)
  • Manufacturer: HDGC
