IRF7904TRPBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IRF7904TRPBF
|
|
حجم فایل
|
74.887
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Type:
2 N-Channel(Half Bridge)
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Infineon Technologies IRF7904TRPBF
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
1.4W;2W
-
Total Gate Charge (Qg@Vgs):
11nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
910pF@15V
-
Continuous Drain Current (Id):
7.6A;11A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.25V@25uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
16.2mΩ@7.6A,10V
-
Package:
SOP-8
-
Manufacturer:
Infineon Technologies
