IRLML6302TRPBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IRLML6302TRPBF
|
|
حجم فایل
|
67.919
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Infineon Technologies IRLML6302TRPBF
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
540mW
-
Total Gate Charge (Qg@Vgs):
3.6nC@4.45V
-
Drain Source Voltage (Vdss):
20V
-
Input Capacitance (Ciss@Vds):
97pF@15V
-
Continuous Drain Current (Id):
780mA
-
Gate Threshold Voltage (Vgs(th)@Id):
1.5V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
600mΩ@4.5V,610mA
-
Package:
SOT-23
-
Manufacturer:
Infineon Technologies
