RXEF017-AP 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: Littelfuse RXEF017-AP
- Hold Current: 170mA
- Trip Current: 340mA
- Power Dissipation: 0.48W
- Current Rating (Max): 40A
- Maximum Time to Trip: 3s
- Operating Temperature: -40°C~+85°C
- Operating Voltage (Max): 60V
- Resistance - Initial (Ri) (Min): 3.3Ω
- Resistance - Post Trip (R1) (Max): 8Ω
- Package: Plugin
- Manufacturer: Littelfuse
