AP30H80K دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
AP30H80K
|
|
حجم فایل
|
57.147
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
ALLPOWER(ShenZhen Quan Li Semiconductor) AP30H80K
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
75W
-
Total Gate Charge (Qg@Vgs):
11.1nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
1.16nF@25V
-
Continuous Drain Current (Id):
75A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.6V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
180pF@25V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
4.8mΩ@10V,20A
-
Package:
TO-252
-
Manufacturer:
ALLPOWER(ShenZhen Quan Li Semiconductor)
