SMD0805-110 数据手册
其他文档
SMD0805-125 3 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: DOWO SMD0805-110
- Hold Current: 1.1A
- Trip Current: 2.2A
- Power Dissipation: 600mW
- Current Rating (Max): 100A
- Maximum Time to Trip: 0.3s
- Operating Temperature: -40°C~+85°C
- Operating Voltage (Max): 6V
- Resistance - Initial (Ri) (Min): 60mΩ
- Resistance - Post Trip (R1) (Max): 210mΩ
- Package: 0805
- Manufacturer: DOWO
