JMSH1004AE دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
JMSH1004AE
|
|
حجم فایل
|
68.679
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Jiangsu JieJie Microelectronics JMSH1004AE
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
250W
-
Total Gate Charge (Qg@Vgs):
66nC@0~10V
-
Drain Source Voltage (Vdss):
100V
-
Input Capacitance (Ciss@Vds):
4398pF@50V
-
Continuous Drain Current (Id):
190A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.7V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
8.5pF@50V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
3mΩ@10V,20A
-
Package:
TO-263-3
-
Manufacturer:
Jiangsu JieJie Microelectronics
