RXEF010-2 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: Littelfuse RXEF010-2
- Hold Current: 100mA
- Trip Current: 200mA
- Power Dissipation: 0.38W
- Current Rating (Max): 40A
- Maximum Time to Trip: 4s
- Operating Temperature: -40°C~+85°C
- Operating Voltage (Max): 60V
- Resistance - Initial (Ri) (Min): 2.5Ω
- Resistance - Post Trip (R1) (Max): 7.5Ω
- Package: Plugin
- Manufacturer: Littelfuse
