TLC-LSMD185/28 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/Resettable Fuses
- Datasheet: TLC Electronic TLC-LSMD185/28
- Hold Current: 1.85A
- Trip Current: 3.7A
- Power Dissipation: 1.5W
- Current Rating (Max): 40A
- Maximum Time to Trip: 2s
- Operating Temperature: -40°C~+85°C
- Operating Voltage (Max): 28V
- Resistance - Initial (Ri) (Min): -
- Resistance - Post Trip (R1) (Max): -
- Package: 2920
- Manufacturer: TLC Electronic
