IPA180N10N3 G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IPA180N10N3 G
|
|
حجم فایل
|
63.551
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Infineon Technologies IPA180N10N3 G
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
30W
-
Total Gate Charge (Qg@Vgs):
25nC@10V
-
Drain Source Voltage (Vdss):
100V
-
Input Capacitance (Ciss@Vds):
1800pF@50V
-
Continuous Drain Current (Id):
28A
-
Gate Threshold Voltage (Vgs(th)@Id):
3.5V@35uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
18mΩ@28A,10V
-
Package:
TO-220FP
-
Manufacturer:
Infineon Technologies
