IRF9383MTRPBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IRF9383MTRPBF
|
|
حجم فایل
|
113.924
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Type:
P Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Infineon Technologies IRF9383MTRPBF
-
Operating Temperature:
-40°C~+150°C@(Tj)
-
Power Dissipation (Pd):
2.1W;113W
-
Total Gate Charge (Qg@Vgs):
130nC@10V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
7305pF@15V
-
Continuous Drain Current (Id):
22A;160A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.4V@150uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
2.9mΩ@22A,10V
-
Package:
MG-WDSON-5
-
Manufacturer:
Infineon Technologies
