KN4401S-RTK/P Datasheet
Datasheet specifications
| Datasheet's name | KN4401S-RTK/P |
|---|---|
| File size | 51.494 KB |
| File type | |
| Number of pages | 3 |
Download Datasheet KN4401S-RTK/P |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: KEC Semicon KN4401S-RTK/P
- Transistor Type: -
- Operating Temperature: +150°C@(Tj)
- Collector Current (Ic): 600mA
- Power Dissipation (Pd): 350mW
- Transition Frequency (fT): 250MHz
- DC Current Gain (hFE@Ic,Vce): 100@150mA,1V
- Collector Cut-Off Current (Icbo): 100nA
- Collector-Emitter Breakdown Voltage (Vceo): 40V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 750mV@500mA,50mA
- Package: SOT-23
- Manufacturer: KEC Semicon
