FH-00186 Datasheet
Datasheet specifications
| Datasheet's name | FH-00186 |
|---|---|
| File size | 45.332 KB |
| File type | |
| Number of pages | 1 |
Download Datasheet FH-00186 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Pitch: 1.27mm
- Category: Connectors/Female Headers
- Datasheet: Liansheng FH-00186
- Row Spacing: 1.27mm
- Mounting Type: Brick nogging
- Number of Rows: 双排
- Contact Plating: Gold
- Holes Direction: Top
- Holes Structure: 2x14P
- Number of Holes: 28P
- Contact Material: Phosphor bronze
- Insulation Height: 4.3mm
- Current Rating (Max): 1A
- Voltage Rating (Max): -
- Welding Temperature (Max): 260°C@10S
- Circular Hole / Square Hole: Square Holes
- Operating Temperature Range: -40°C~+105°C
- Package: SMD,P=1.27mm
- Manufacturer: Liansheng
