دیتاشیت MP13N50
مشخصات دیتاشیت
| نام دیتاشیت |
MP13N50
|
| حجم فایل |
31.797
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
3
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Minos MP13N50
-
Operating Temperature:
+175°C@(Tj)
-
Power Dissipation (Pd):
60W
-
Total Gate Charge (Qg@Vgs):
40nC@10V
-
Drain Source Voltage (Vdss):
500V
-
Input Capacitance (Ciss@Vds):
2315pF@25V
-
Continuous Drain Current (Id):
13A
-
Gate Threshold Voltage (Vgs(th)@Id):
3.1V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
11pF@25V
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
340mΩ@10V,6.5A
-
Package:
TO-220
-
Manufacturer:
Minos
