CJPF12N65 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CJPF12N65
|
|
حجم فایل
|
74.484
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Jiangsu Changjing Electronics Technology Co., Ltd. CJPF12N65
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
50W
-
Total Gate Charge (Qg@Vgs):
42nC
-
Drain Source Voltage (Vdss):
650V
-
Input Capacitance (Ciss@Vds):
1800pF
-
Continuous Drain Current (Id):
12A
-
Gate Threshold Voltage (Vgs(th)@Id):
30V
-
Reverse Transfer Capacitance (Crss@Vds):
25pF
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
700mΩ@10V
-
Package:
TO-220F
-
Manufacturer:
Jiangsu Changjing Electronics Technology Co., Ltd.
