147873-2 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Circuit: SPST
- Category: Key/Switch/Tactile Switches
- Datasheet: TE Connectivity 147873-2
- Pin Style: J pin
- Switch Width: 3.5mm
- Strike Gundam: NO
- Switch Height: 4.3mm
- Switch Length: 6mm
- Actuator Style: Rectangle button
- Mounting Style: Brick nogging
- Contact Current: 50mA
- Mechanical Life: 40000次
- Operating Force: 180gf
- Actuator/Cap Color: Black
- Voltage Rating (DC): 24V
- Insulation Resistance: 100MΩ
- Operating Temperature: -35°C~+85°C
- Package: SMD
- Manufacturer: TE Connectivity
