ACT1210-510-2P-TL00 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: Bead/Filter/EMI Optimization/Common Mode Filters
- Datasheet: TDK ACT1210-510-2P-TL00
- Current Rating: 200mA
- Number of Lines: 2
- DC Resistance (DCR): 700mΩ
- Voltage Rating - DC: 80V
- Impedance @ Frequency: 2.6kΩ@10MHz
- Operating Temperature: -55°C~+150°C
- Inductance @ Frequency: 51uH@100kHz
- Package: 3.2x2.5mm
- Manufacturer: TDK
