CSD18510KTT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CSD18510KTTT
|
|
حجم فایل
|
81.734
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Texas Instruments CSD18510KTT
-
Operating Temperature:
-55°C~+175°C@(Tj)
-
Power Dissipation (Pd):
250W
-
Total Gate Charge (Qg@Vgs):
153nC@10V
-
Drain Source Voltage (Vdss):
40V
-
Input Capacitance (Ciss@Vds):
11400pF@20V
-
Continuous Drain Current (Id):
274A
-
Gate Threshold Voltage (Vgs(th)@Id):
2.3V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
1.7mΩ@100A,10V
-
Package:
TO-263-3
-
Manufacturer:
Texas Instruments
