IRF7307TRPBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
IRF7307TRPBF
|
|
حجم فایل
|
71.981
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
10
|
مشخصات فنی
-
RoHS:
true
-
Type:
-
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Infineon Technologies IRF7307TRPBF
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
2W
-
Total Gate Charge (Qg@Vgs):
20nC@4.5V
-
Input Capacitance (Ciss@Vds):
660pF@15V
-
Continuous Drain Current (Id):
5.2A;4.3A
-
Gate Threshold Voltage (Vgs(th)@Id):
700mV@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
50mΩ@2.6A,4.5V
-
Package:
SOP-8
-
Manufacturer:
Infineon Technologies
