دیتاشیت STM32F401RET6

مشخصات دیتاشیت

دانلود دیتاشیت STM32F401xD, STM32F401xE	STM32F401xD, STM32F401xE Datasheet

RoHS: true
CPU Core: ARM Cortex-M4
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
Datasheet: STMicroelectronics STM32F401RET6
CPU Maximum Speed: 84MHz
GPIO Ports Number: 50
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Direct Memory Access: Yes
Program Storage Size: 512KB
Universal Serial Bus: Yes
Operating Voltage Range: 1.7V~3.6V
Infrared Data Association: Yes
Operating Temperature Range: -40°C~+85°C
Secure Digital Input and Output: Yes
Package: LQFP-64(10x10)
Manufacturer: STMicroelectronics
Series: STM32F4
Packaging: Tray
Part Status: Active
Core Processor: ARM® Cortex®-M4
Core Size: 32-Bit
Speed: 84MHz
Connectivity: I²C, IrDA, LINbus, SDIO, SPI, UART/USART, USB OTG
Peripherals: Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
Number of I/O: 50
Program Memory Size: 512KB (512K x 8)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 96K x 8
Voltage - Supply (Vcc/Vdd): 1.7V ~ 3.6V
Data Converters: A/D 16x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 64-LQFP
Supplier Device Package: 64-LQFP (10x10)
Base Part Number: STM32F401
