دیتاشیت STM32H750XBH6
مشخصات دیتاشیت
| نام دیتاشیت | STM32H750xB Datasheet |
|---|---|
| حجم فایل | 4735.485 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 335 |
دانلود دیتاشیت STM32H750xB Datasheet |
STM32H750xB Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- CPU Core: ARM-MSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 16bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32H750XBH6
- LCD Module: Yes
- CPU Maximum Speed: 480MHz
- GPIO Ports Number: 168
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Direct Memory Access: Yes
- Program Storage Size: 128KB
- Universal Serial Bus: Yes
- Operating Voltage Range: 1.62V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: Yes
- Package: TFBGA-265
- Manufacturer: STMicroelectronics
- Series: STM32H7
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M7
- Core Size: 32-Bit
- Speed: 480MHz
- Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
- Number of I/O: 168
- Program Memory Size: 128KB (128K x 8)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 1M x 8
- Voltage - Supply (Vcc/Vdd): 1.62V ~ 3.6V
- Data Converters: A/D 36x16b; D/A 2x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 265-TFBGA
- Supplier Device Package: 240+25-TFBGA (14x14)
- Base Part Number: STM32H750
- detail: ARM® Cortex®-M7 STM32H7 Microcontroller IC 32-Bit 480MHz 128KB (128K x 8) FLASH 240+25-TFBGA (14x14)
