دیتاشیت STM32F303RET6

مشخصات دیتاشیت

دانلود دیتاشیت STM32F303xD, STM32F303xE Datasheet	STM32F303xD, STM32F303xE Datasheet Datasheet

RoHS: true
EEPROM: -
CPU Core: ARM Cortex-M4
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
RAM Size: 80KB
Watchdog: Yes
ADC (Bit): 12bit
DAC (Bit): 12bit
Datasheet: STMicroelectronics STM32F303RET6
PWM (Bit): -
Real-Time Clock: -
CPU Maximum Speed: 72MHz
GPIO Ports Number: 51
Low-Voltage Detect: Yes
CCP Capture/Compare: -
Internal Comparator: -
Internal Oscillator: Yes
Peripheral/Function: DMA;WDT
Program Memory Type: FLASH
Direct Memory Access: Yes
Program Storage Size: 512KB
Universal Serial Bus: Yes
communication protocol: -
Operating Voltage Range: 2V~3.6V
Infrared Data Association: Yes
Operating Temperature Range: -40°C~+85°C
Secure Digital Input and Output: -
Package: LQFP-64(10x10)
Manufacturer: STMicroelectronics
Series: STM32F3
Packaging: Tray
Part Status: Active
Core Processor: ARM® Cortex®-M4
Core Size: 32-Bit
Speed: 72MHz
Connectivity: CANbus, I²C, IrDA, LINbus, SPI, UART/USART, USB
Peripherals: DMA, I²S, POR, PWM, WDT
Number of I/O: 51
Program Memory Size: 512KB (512K x 8)
EEPROM Size: -
Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
Data Converters: A/D 22x12b; D/A 2x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 64-LQFP
Supplier Device Package: 64-LQFP (10x10)
Base Part Number: STM32F303
