دیتاشیت STM32F101CBT6

مشخصات دیتاشیت

دانلود دیتاشیت STM32F101x8, STM32F101xB	STM32F101x8, STM32F101xB Datasheet

RoHS: true
EEPROM: -
CPU Core: ARM Cortex-M3
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
RAM Size: 16KB
Watchdog: Yes
ADC (Bit): 12bit
DAC (Bit): -
Datasheet: STMicroelectronics STM32F101CBT6
PWM (Bit): -
Real-Time Clock: -
CPU Maximum Speed: 36MHz
GPIO Ports Number: 37
Low-Voltage Detect: Yes
CCP Capture/Compare: -
Internal Comparator: -
Internal Oscillator: Yes
Peripheral/Function: DMA;PWM;On-chip temperature sensor
Program Memory Type: FLASH
Direct Memory Access: Yes
Program Storage Size: 128KB
Universal Serial Bus: -
communication protocol: -
Operating Voltage Range: 2V~3.6V
Infrared Data Association: Yes
Operating Temperature Range: -40°C~+85°C
Secure Digital Input and Output: -
Package: LQFP-48(7x7)
Manufacturer: STMicroelectronics
Series: STM32F1
Packaging: Tray
Part Status: Active
Core Processor: ARM® Cortex®-M3
Core Size: 32-Bit
Speed: 36MHz
Connectivity: I²C, IrDA, LINbus, SPI, UART/USART
Peripherals: DMA, PDR, POR, PVD, PWM, Temp Sensor, WDT
Number of I/O: 37
Program Memory Size: 128KB (128K x 8)
EEPROM Size: -
Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
Data Converters: A/D 10x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 48-LQFP
Supplier Device Package: 48-LQFP (7x7)
Base Part Number: STM32F101
