دیتاشیت STM32F051R8T6
مشخصات دیتاشیت
| نام دیتاشیت | STM32F051x4, x6, x8 Datasheet |
|---|---|
| حجم فایل | 2040.88 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 122 |
دانلود دیتاشیت STM32F051x4, x6, x8 Datasheet |
STM32F051x4, x6, x8 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- CPU Core: ARM Cortex-M0
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32F051R8T6
- CPU Maximum Speed: 48MHz
- GPIO Ports Number: 55
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Direct Memory Access: Yes
- Program Storage Size: 64KB
- Operating Voltage Range: 2V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Package: LQFP-64(10x10)
- Manufacturer: STMicroelectronics
- Series: STM32F0
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M0
- Core Size: 32-Bit
- Speed: 48MHz
- Connectivity: HDMI-CEC, I²C, IrDA, LINbus, SPI, UART/USART
- Peripherals: DMA, I²S, POR, PWM, WDT
- Number of I/O: 55
- Program Memory Size: 64KB (64K x 8)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 8K x 8
- Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
- Data Converters: A/D 19x12b; D/A 1x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 64-LQFP
- Base Part Number: STM32F05
