دیتاشیت STM32G071RBT6

مشخصات دیتاشیت

دانلود دیتاشیت STM32G071x(8, B) Datasheet	STM32G071x(8, B) Datasheet Datasheet

RoHS: true
CPU Core: ARM-MSeries
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
DAC (Bit): 12bit
Datasheet: STMicroelectronics STM32G071RBT6
CPU Maximum Speed: 64MHz
GPIO Ports Number: 60
Low-Voltage Detect: Yes
Internal Oscillator: Yes
Peripheral/Function: Temperature transducer
Direct Memory Access: Yes
Program Storage Size: 128KB
Universal Serial Bus: Yes
Operating Voltage Range: 1.71V~3.6V
Infrared Data Association: Yes
Operating Temperature Range: -40°C~+85°C
Package: LQFP-64(10x10)
Manufacturer: STMicroelectronics
Series: STM32G0
Packaging: Tray
Part Status: Active
Core Processor: ARM® Cortex®-M0+
Core Size: 32-Bit
Speed: 64MHz
Connectivity: HDMI-CEC, I²C, IrDA, LINbus, SPI, UART/USART, USB
Peripherals: Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
Number of I/O: 60
Program Memory Size: 128KB (128K x 8)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 36K x 8
Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
Data Converters: A/D 19x12b; D/A 2x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 64-LQFP
Supplier Device Package: 64-LQFP (10x10)
Base Part Number: STM32G071
detail: ARM® Cortex®-M0+ STM32G0 Microcontroller IC 32-Bit 64MHz 128KB (128K x 8) FLASH 64-LQFP (10x10)
