دیتاشیت ATMEGA64-16AU

ATmega64(L) Summary

مشخصات دیتاشیت

نام دیتاشیت ATmega64(L) Summary
حجم فایل 309.356 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت ATmega64(L) Summary

ATmega64(L) Summary Datasheet

مشخصات

  • RoHS: true
  • CPU Core: AVR
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • Watchdog: Yes
  • ADC (Bit): 10bit
  • Datasheet: Microchip Tech ATMEGA64-16AU
  • CPU Maximum Speed: 16MHz
  • GPIO Ports Number: 53
  • Low-Voltage Detect: Yes
  • Internal Oscillator: Yes
  • Program Storage Size: 64KB
  • Operating Voltage Range: 4.5V~5.5V
  • Operating Temperature Range: -40°C~+85°C
  • Package: TQFP-64(14x14)
  • Manufacturer: Microchip Tech
  • Series: AVR® ATmega
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: AVR
  • Core Size: 8-Bit
  • Speed: 16MHz
  • Connectivity: I²C, SPI, UART/USART
  • Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
  • Number of I/O: 53
  • Program Memory Size: 64KB (32K x 16)
  • Program Memory Type: FLASH
  • EEPROM Size: 2K x 8
  • RAM Size: 4K x 8
  • Voltage - Supply (Vcc/Vdd): 4.5V ~ 5.5V
  • Data Converters: A/D 8x10b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 64-TQFP
  • Supplier Device Package: 64-TQFP (14x14)
  • Base Part Number: ATMEGA64
