دیتاشیت STM32H747IIT6

مشخصات دیتاشیت

نام دیتاشیت	STM32H747x(I, G) Datasheet
حجم فایل	3529.52 کیلوبایت
نوع فایل	pdf
تعداد صفحات	252

دانلود دیتاشیت STM32H747x(I, G) Datasheet	STM32H747x(I, G) Datasheet Datasheet

مشخصات

CAN: -
I2C: -
I2S: -
SPI: -
RoHS: true
EEPROM: -
CPU Core: ARMOther series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
RAM Size: 1MB
Watchdog: Yes
ADC (Bit): 16bit
DAC (Bit): 12bit
Datasheet: STMicroelectronics STM32H747IIT6
PWM (Bit): -
8Bit Timer: -
LCD Module: Yes
UART/USART: -
16Bit Timer: -
32Bit Timer: -
Real-Time Clock: -
CPU Maximum Speed: 240MHz;480MHz
GPIO Ports Number: 168
Low-Voltage Detect: Yes
CCP Capture/Compare: -
Internal Comparator: -
Internal Oscillator: Yes
Peripheral/Function: DMA;LCD/LED Driver
Program Memory Type: FLASH
Direct Memory Access: Yes
Program Storage Size: 2MB
Universal Serial Bus: Yes
communication protocol: -
Operating Voltage Range: 1.62V~3.6V
Infrared Data Association: Yes
Operating Temperature Range: -40°C~+85°C
Secure Digital Input and Output: Yes
Package: LQFP-176(24x24)
Manufacturer: STMicroelectronics
Series: STM32H7
Packaging: Tray
Part Status: Active
Core Processor: ARM® Cortex®-M4, Cortex®-M7
Core Size: 32-Bit Dual-Core
Speed: 240MHz, 480MHz
Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Number of I/O: 168
Program Memory Size: 2MB (2M x 8)
EEPROM Size: -
Voltage - Supply (Vcc/Vdd): 1.62V ~ 3.6V
Data Converters: A/D 28x16b; D/A 2x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 176-LQFP
Supplier Device Package: 176-LQFP (24x24)
detail: ARM® Cortex®-M4, Cortex®-M7 STM32H7 Microcontroller IC 32-Bit Dual-Core 240MHz, 480MHz 2MB (2M x 8) FLASH 176-LQFP (24x24)
