دیتاشیت STM32F767BIT6

مشخصات دیتاشیت

دانلود دیتاشیت STM32F765xx,767xx, 768Ax, 769xx	STM32F765xx,767xx, 768Ax, 769xx Datasheet

Manufacturer: STMicroelectronics
Series: STM32F7
Packaging: Tray
Part Status: Active
Core Processor: ARM® Cortex®-M7
Core Size: 32-Bit
Speed: 216MHz
Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, UART/USART, USB OTG
Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
Number of I/O: 159
Program Memory Size: 2MB (2M x 8)
Program Memory Type: FLASH
EEPROM Size: -
RAM Size: 512K x 8
Voltage - Supply (Vcc/Vdd): 1.7V ~ 3.6V
Data Converters: A/D 24x12b; D/A 2x12b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 208-LQFP
Supplier Device Package: 208-LQFP (28x28)
Base Part Number: STM32F767
