دیتاشیت ATMEGA325V-8AU

ATMEGA325, 645, 3250, 6450(V) Summary

مشخصات دیتاشیت

نام دیتاشیت ATMEGA325, 645, 3250, 6450(V) Summary
حجم فایل 913.072 کیلوبایت
نوع فایل pdf
تعداد صفحات 29

دانلود دیتاشیت ATMEGA325, 645, 3250, 6450(V) Summary

ATMEGA325, 645, 3250, 6450(V) Summary Datasheet

مشخصات

  • RoHS: true
  • CPU Core: AVR
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • Watchdog: Yes
  • ADC (Bit): 10bit
  • Datasheet: Microchip Tech ATMEGA325V-8AU
  • CPU Maximum Speed: 8MHz
  • GPIO Ports Number: 54
  • Low-Voltage Detect: Yes
  • Internal Oscillator: Yes
  • Program Storage Size: 32KB
  • Operating Voltage Range: 1.8V~5.5V
  • Operating Temperature Range: -40°C~+85°C
  • Package: TQFP-64(14x14)
  • Manufacturer: Microchip Tech
  • Series: AVR® ATmega
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: AVR
  • Core Size: 8-Bit
  • Speed: 8MHz
  • Connectivity: SPI, UART/USART, USI
  • Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
  • Number of I/O: 54
  • Program Memory Size: 32KB (16K x 16)
  • Program Memory Type: FLASH
  • EEPROM Size: 1K x 8
  • RAM Size: 2K x 8
  • Voltage - Supply (Vcc/Vdd): 1.8V ~ 5.5V
  • Data Converters: A/D 8x10b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 64-TQFP
  • Supplier Device Package: 64-TQFP (14x14)
  • Base Part Number: ATMEGA325
