دیتاشیت ATMEGA32U2-AU
مشخصات دیتاشیت
| نام دیتاشیت | ATMEGA8/16/32U2 Summary |
|---|---|
| حجم فایل | 327.434 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت ATMEGA8/16/32U2 Summary |
ATMEGA8/16/32U2 Summary Datasheet |
|---|
مشخصات
- RoHS: true
- CPU Core: AVR
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- Datasheet: Microchip Tech ATMEGA32U2-AU
- CPU Maximum Speed: 16MHz
- GPIO Ports Number: 22
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Program Storage Size: 32KB
- Universal Serial Bus: Yes
- Operating Voltage Range: 2.7V~5.5V
- Operating Temperature Range: -40°C~+85°C
- Package: TQFP-32(7x7)
- Manufacturer: Microchip Tech
- Series: AVR® ATmega
- Packaging: Tray
- Part Status: Active
- Core Processor: AVR
- Core Size: 8-Bit
- Speed: 16MHz
- Connectivity: SPI, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O: 22
- Program Memory Size: 32KB (16K x 16)
- Program Memory Type: FLASH
- EEPROM Size: 1K x 8
- RAM Size: 1K x 8
- Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
- Data Converters: -
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 32-TQFP
- Supplier Device Package: 32-TQFP (7x7)
- Base Part Number: ATMEGA32U2
