ATMEGA16(L) Summary Datasheet

ATMEGA16(L) Summary

Datasheet specifications

Datasheet's name ATMEGA16(L) Summary
File size 644.978 KB
File type pdf
Number of pages 26

Download Datasheet ATMEGA16(L) Summary

Download Datasheet

Other documentations

ATMEGA16(L) Datasheet 357 pages

Technical specifications

  • RoHS: true
  • CPU Core: AVR
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • Watchdog: Yes
  • ADC (Bit): 10bit
  • Datasheet: Microchip Tech ATMEGA16L-8AU
  • CPU Maximum Speed: 8MHz
  • GPIO Ports Number: 32
  • Low-Voltage Detect: Yes
  • Internal Oscillator: Yes
  • Program Storage Size: 16KB
  • Operating Voltage Range: 2.7V~5.5V
  • Operating Temperature Range: -40°C~+85°C
  • Package: TQFP-44(10x10)
  • Manufacturer: Microchip Tech
  • Series: AVR® ATmega
  • Packaging: Tray
  • Part Status: Active
  • Core Processor: AVR
  • Core Size: 8-Bit
  • Speed: 8MHz
  • Connectivity: I²C, SPI, UART/USART
  • Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
  • Number of I/O: 32
  • Program Memory Size: 16KB (8K x 16)
  • Program Memory Type: FLASH
  • EEPROM Size: 512 x 8
  • RAM Size: 1K x 8
  • Voltage - Supply (Vcc/Vdd): 2.7V ~ 5.5V
  • Data Converters: A/D 8x10b
  • Oscillator Type: Internal
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 44-TQFP
  • Supplier Device Package: 44-TQFP (10x10)
  • Base Part Number: ATMEGA16
